WI232+ MB - Advanced WiFi to Serial Device Server: DCE (female - 110v Supply

$169.00

Leave a review

SKU: GC-WI232-PLUS-DCE-MB-110

MPN: GC-WI232-PLUS-DCE-MB-110

Manufacturer: Grid Connect Inc.

Stock Status: In stock

Delivery: Ships within 1-2 business days
Qualifies for Free shipping to the US

Connector Type

Power Supply

We Have You Covered

Price Match delivery truck hand receiving items

30 day money back guarantee

*some exceptions apply

Product Information

Product Description

The WI232+ MB is the next generation of Wi-Fi to serial Modbus gateway servers. Besides new enhanced software features, there are the following capabilities.

  • “Soft-AP” which makes getting the WI232+ configured and connected to a Wi-Fi network simple
  • Factory reset push button (accessible with a pin or paperclip)
  • Smaller form factor

The WI232+ is simple to configure using the Soft AP feature. When it is powered-up, the WI232 broadcasts an easy to recognize SSID. Simply join its WiFi Network with your smartphone, tablet or wireless PC, and a configuration webpage will display. This page is where you can set up the serial port, and provide the credentials for the WI232+ to join your WiFi network.

The WI232+ can be used to “tunnel” serial Modbus communication or to bridge between Modbus/TCP and Modbus serial protocols. The WI232+ converts a serial Modbus RTU/ASCII device into an Ethernet Modbus TCP device. All standard Modbus commands and messages are automatically converted. The limitations of a serial network are removed.

Custom versions, board level, white-label and private label versions available.

Order Summary



SKU

Connector Type

Power Supply

Manufacturer Part # (MPN)
GC-WI232-PLUS-DTE-MB-110 DTE (male) 110v GC-WI232-PLUS-DTE-MB-110
GC-WI232-PLUS-DTE-MB-TB DTE (male) Terminal Block GC-WI232-PLUS-DTE-MB-TB
GC-WI232-PLUS-DCE-MB-110 DCE (female) 110v GC-WI232-PLUS-DCE-MB-110
GC-WI232-PLUS-DCE-MB-TB DCE (female) Terminal Block GC-WI232-PLUS-DCE-MB-TB

Features

  • Modbus/TCP bridge to Modbus/RTU or ASCII
  • Web Page Configuration and powerful Web API
  • Simultaneous Soft AP and client mode
  • Supports multiple TCP Connections
  • LEDs for Power / Link
  • DTE (male) and DCE (female) versions
  • Custom versions available
  • Serial rates up to 921K
  • Supports TX, RX, CTS, RTS, DSR and DTR serial signals
  • Industrial temp rated
  • Power via Wall Supply, USB power cable, or Terminal Block
  • Factory Reset Button

Documents and Drivers

Documentation

WI232+ Modbus/TCP Datasheet

Specifications

Antennas

4.3 inch Omni-directional “rubber duck” antenna, 2.4GHz, 2.5 dB, RPSMA, 50Ohm, 20W

Certifications

  • FCC Part 15, Subpart B, Class B
  • RoHS, CE (Pending), UL

Connector(s)

DB9 Connector (Male or Female) – custom versions possible

Data Bits

7 or 8

Dimensions

  • Housing: 63.5 x 42.67 x 20.17mm (2.5 x 1.58 x 0.794 inches)
  • Cable Length (including DB9 connector): 460.375mm (18.125 inches)

Firmware

Upgradeable Over the Air (OTA)

Humidity

5% to 95% non-condensing

Interface(s)

  • Wi-Fi Interface: 802.11b/g and 802.11n (single stream)
  • WLAN Interface: 2.4 GHz only
  • IEEE 802.11 d/h/i/j/k/w/r
  • WPS2.0 Support
  • TCP/IP, UDP/IP, Modbus/TCP, DHCP, ARP, ICMP, SNMPv1, DNS, Auto IP

MPN

  • GC-WI232-PLUS-DCE-MB-110
  • GC-WI232-PLUS-DCE-MB-TB
  • GC-WI232-PLUS-DTE-MB-110
  • GC-WI232-PLUS-DTE-MB-TB

Product Weight

62.4 g (2.2 oz)

Security/Protection

256-bit AES Encryption (Tunnel Mode)

Software

Virtual COM port software

Stop Bits

1 or 2

Temperature Range

-40°C to +85°C (-40°F to +185°F)
