Product Information
Product Description
RUT951 features dual-SIM cellular connectivity combined with Wi-Fi and 4 Ethernet interfaces to meet the needs of most varied IoT scenarios. Powered by RutOS, this router offers advanced customization options, automation features, and top-level security for your solution.
An automatic WAN failover to an available backup connection ensures network continuity and eliminates downtime.
Compatibility with the Teltonika Networks Remote Management System (RMS) enables secure remote management to save time and expenses.
Package includes
• Router RUT951
• 9 W PSU
• 2 x LTE antennas (swivel, SMA male)
• 2 x WiFi antennas (swivel, RP-SMA male)
• Ethernet cable (1.5 m)
• SIM Adapter kit
• QSG (Quick Start Guide)
Features
- Connectivity - 4G LTE (Cat 4), 3G, 2G
- Dual SIM - with auto failover, backup WAN and other switching scenarios
- Wi-Fi - Wireless Access Point with Hotspot functionality
- WAN Failover - automatic switching to available backup connection
Documents and Drivers
Documentation
RUT951 Flyer
RUT951 Datasheet
RUT951 Quick Start Guide
RUT951 User Manual
RUT951 Certification and Approvals
Specifications
HARDWARE
4G/LTE (Cat 4), 3G, 2G
CPU
Mediatek, 580 MHz, MIPS 24KEc
Storage
16 MB Flash
Memory
128 MB RAM
Powering option
4pin power socket, 9-30 VDC
Antenna connectors
2 x SMA for mobile, 2 x RP-SMA for WiFi
Ethernet
4 x 10/100 Ethernet ports: 1 x WAN (configurable as LAN), 3 x LAN
WiFi
IEEE 802.11b/g/n, Access point (AP), Station (STA)
Inputs/Outputs
On 4pin socket: 1 x Digital input, 1 x Digital open collector output
SIM
2 x External SIM holders (2FF)
Status LEDs
1 x Bi-Color connection type, 5 x Signal strength, 4 x Ethernet, 1 x Power
Operating temperature
-40°C ~ 75°C (-40°F ~ 167°F)
Housing
Aluminum housing with DIN rail mounting option, plastic panels with flat mounting option
Dimensions
110 x 50 x 100 mm) (4.3 x 2.0 x 4.0 in)
Weight
278 g (0.6 lbs)
SOFTWARE
Operating system
RutOS (OpenWrt based Linux OS)
Mobile features
Auto APN, Band lock, SIM switch, Operator black/white list, Data/SMS limits
Network
Failover (Network backup), VLAN, QoS, Load Balancing
Routing
Static routes, Dynamic routes (BGP, OSPFv2, RIPv1/v2, EIGRP, NHRP), Routing rules
VPN and tunneling
OpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, ZeroTier, WireGuard
Monitoring and Management
WEB UI, CLI, SSH, CALL, SMS, TR-069, SNMP, JSON-RPC, MQTT, MODBUS, RMS
Connection monitoring
Ping Reboot, Wget reboot, Periodic Reboot, LCP and ICMP for link inspection
Cloud solutions
RMS, FOTA, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx
Hotspot
External/Internal Radius, SMS OTP, MAC authentication, Walled Garden
Supported Hotspot platforms
IronWiFi, HotspotSystem, Cloud4Wi, SAI + WiFi, MugiCloud, Purple.ai
SMS features
SMS status, SMS configuration, Send/Read SMS via HTTP POST/GET, EMAIL to SMS, SMS to Email, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP
Services
DDNS, VRRP, Wake On Lan (WOL), WEB filter, UPNP, Traffic Logging
