Programmable CAN bus to RS232 Adapter (PCAN-RS232)
Programmable CAN bus to RS232 Adapter
Programmable CAN bus to RS232 Adapter Side
Programmable CAN bus to RS232 Adapter (PCAN-RS232)
Product Images
Programmable CAN bus to RS232 Adapter (PCAN-RS232)
$180.00
5.0 stars 5.0 (2) See customer reviews
SKU: GC-CAN-RS232-PGM
MPN: IPEH-002100
Manufacturer: Peak System Technik
Stock Status: In stock
Delivery: Ships same or next business day
Qualifies for Free shipping to the US
We Have You Covered
Skip To Footer
Product Information
Product Description
Convert RS232 serial data to CAN bus with the programmable PCAN-RS232 adapter. Use the default program supplied with the adapter or program your own software into the adapter to customize it to your protocol.
The PCAN-RS232 converter has one CAN channel and one RS232 port. The data traffic between CAN and RS232 is controlled by a freely programmable microcontroller. Thus, devices without CAN connection (e.g. PLC systems) can be connected to a CAN bus via almost any RS232 protocol.
The provided library and Yagarto toolchain can be used to produce your own firmware and then transfer it to the converter via CAN. This capability gives a whole range of options for manipulation, evaluation, filtering, and routing of the data traffic.
The PCAN-RS232 converter is delivered with example firmware that routes from CAN to RS232 and vice versa. It allows you to configure the data transfer as well as the hardware with serial control commands. The corresponding source code is included.
NOTE: To configure or transfer firmware via CAN, a Peak CAN interface is required.
Features
- NXP LPC21 microcontroller (16/32-bit ARM CPU)
- 32K bytes EEPROM
- 1x physical CAN channel, baud rates up to 1M
- 1x RS232 serial port, baud rates up to 115.2K
- 1x digital input, 1x digital output
- 2 color LED functions
- 10 position terminal block connectors for RS232, CAN, Power, I/O
Documents and Drivers
Documentation
PCAN-RS232 User Manual
Downloads
PEAK-Flash 2
PEAK-DevPack - Development package for ARM-based products
CAN Download Support
View the available Peak System downloads:
Specifications
Certifications
CE
Connector(s)
10 position terminal block connectors for RS232, CAN, Power, I/O
Dimensions
68 x 57 x21 mm
Enclosure
IP20 Aluminum
Mounting
Din Rail or Wall Mount
MPN
IPEH-002100
Power
8 to 30 Volts DC (70mA @ 12V)
Product Weight
36 grams
Temperature Range
-40ºC to 85ºC (-40ºF to 185ºF)
Warranty
