CAN@net NT 420 - 4 CAN channels (2 CAN FD) Ethernet Bridge with MQTT

The Ixxat CAN@net NT 420 is a multifunctional gateway, bridging CAN and Ethernet networks for remote access and enhanced reliability. It features 4 CAN channels of which 2 are CAN FD capable.   Long-distance communication is supported with several message processing and cloud connection functionalities.

Three operation modes in one device

• PC operation mode with VCI driver support enables easy integration into PC-based Ixxat applications and customer-specific programs. Ideal for configuration, analysis and maintenance.
• Bridge operation mode enables CAN system expansion and easy message exchange between CAN/CAN FD systems, or over Ethernet, to setup tree or star topologies or to enable long-range communication.
• CAN Ethernet gateway mode enables the device to be accessed regardless of the operating system or platform by using a simple ASCII protocol via TCP/IP socket.

FOR CAN and CAN FD

Four independent CAN channels, two of which can be switched via software to CAN FD.

Cost savings from simple wiring

Optimized topologies enable simpler wiring in CAN systems. This reduces the need for complex cabling, thus, leading to cost savings in installation and maintenance.

On device intelligence

Advanced filter, ID translation, data mapping and multiplexing functionalities streamline network traffic and enhance efficiency.

Customizable actions

Additional programming of action rules using LUA enables tailored responses to specific network events.

Device and system protection

Network segmentation with galvanic isolation protects devices against damage caused by voltage peaks.

Cloud connection

MQTT support allows direct transmission of information to the cloud, facilitating IoT and remote monitoring applications.

Configurable security levels

Defined assess levels for configuration or firmware upload.

Easy configuration and maintenance

Windows configuration tool allows for easy setup and maintenance via USB or Ethernet
