$195.00
This product is discontinued and no longer available.
ADAM 6050 - 18 Channel Digital I/O Ethernet and Modbus TCP Module
ADAM 6050 - 18 Channel Digital I/O Ethernet and Modbus TCP Module
Product Images
ADAM 6050 - 18 Channel Digital I/O Ethernet and Modbus TCP Module
SKU: GC-ADAM-6050-D
MPN: ADAM-6050-D
Manufacturer: Advantech
We Have You Covered
Skip To Footer
Product Information
Product Description
The ADAM 6050 allows the integration of automation and enterprise systems through internet technology. It is a high-density IO module built-in a 10/100Mbps interface for seamless Ethernet connectivity. It provides 12 digital input and 6 digital output channels with 2000VRMS Isolating protection.
The module can be remotely monitored and controlled with mobile devices using MQTT publish and subscribe methods. It provides intelligent stand-alone control capabilities using Peer-to-Peer (P2P) and Graphic Condition Logic (GCL).
The ADAM 6050 supports the following protocols:
- Modbus/TCP
- TCP/IP
- UDP
- HTTP
- DHCP
- SNMP
- MQTT
Features
- Provides default/customized web page
- Supports Dry/Wet contact
- Group configuration for multiple module setup
- User-defined Modbus address
- Active I/O message by data stream or event trigger function
- Web languages: XML, HTML 5, Java Script
Documents and Drivers
Documentation
ADAM 6050 Datasheet
ADAM MQTT Manual
Specifications
Channels
- 12 Digital Input
- 6 Digital Output
Communication
- Speed: Ethernet 10/100 Mbps
- Distance: Ethernet 100m
- Web Language: XML , HTML5 , Java Script
Connector(s)
1 x RJ-45 (LAN) & 2 x plug-in terminal block (I/O and power)
GTIN
634420348666
Indicators LED
Status, Comm, Link, Speed
Input/Output
Dry Contact
- Logic Level 0: Close to GND
- Logic Level 1: Open
Wet Contact
- Logic Level 0: 0~3 VDC
- Logic Level 1: 10~30 VDC
Interface(s)
10/100 Base-T(X)
IO Type
12 DI & 6 DO
Isolation
2000 VDC
MPN
ADAM-6050-D
Power Consumption
10~30 VDC
Protocols
- Modbus/TCP
- TCP/IP
- UDP
- HTTP
- DHCP
- SNMP
- MQTT
Temperature Range
- Operating: -40ºC to 70ºC (-40ºF to 158ºF)
- Storage: -40ºC to 80ºC (-40ºF to 176ºF)
Watchdog Timer
System (1.6 second) & Communication (programmable)
