CAN@net NT 200 - CAN Ethernet bridge/gateway (2 channels) with MQTT
CAN Ethernet gateway, bridge and PC interface all in 1 device,
CAN@net NT 200 - CAN Ethernet bridge/gateway (2 channels) with MQTT
Product Images
CAN@net NT 200 - CAN Ethernet bridge/gateway (2 channels) with MQTT
$697.00
SKU: GC-IXT-NT200
MPN: 1.01.0332.20000
Manufacturer: Ixxat
We Have You Covered
Product Information
Product Description
The Ixxat CAN@net NT 200 is a multifunctional gateway, bridging CAN networks via Ethernet for remote access and enhanced reliability. It features two CAN channels and supports long-distance communication, with several message processing and cloud connection functionalities.
Three operation modes in one device
The Ixxat CAN@net NT can be used as a PC interface, as a CAN-Ethernet-CAN bridge or as a CAN Ethernet gateway – all in one device.
- PC operation mode with VCI driver support enables easy integration into PC-based Ixxat applications and customer-specific programs. Ideal for configuration, analysis and maintenance.
- Bridge operation mode enables CAN system expansion and easy message exchange between CAN systems, or over Ethernet, to setup tree or star topologies or to enable long-range communication.
- CAN Ethernet gateway mode enables the device to be accessed regardless of the operating system or platform, using a simple ASCII protocol via TCP/IP socket.
Cost savings from simple wiring
Optimized topologies enable simpler wiring in CAN systems. This reduces the need for complex cabling, thus, leading to cost savings in installation and maintenance.
On device intelligence
Advanced filter, ID translation, data mapping and multiplexing functionalities streamline network traffic and enhance efficiency.
Customizable actions
Additional programming of action rules using LUA enables tailored responses to specific network events.
Device and system protection
Network segmentation with galvanic isolation protects devices against damage caused by voltage peaks.
Cloud connection
MQTT support allows direct transmission of information to the cloud, facilitating IoT and remote monitoring applications.
Configurable security levels
Defined assess levels for configuration or firmware upload.
Easy configuration and maintenance
Windows configuration tool allows for easy setup and maintenance via USB or Ethernet.
Features
- Three operation modes in one device
- PC operation mode with VCI driver support
- Bridge operation enables CAN system expansion
- CAN Ethernet gateway for flexible access
- Cost savings due to simple wiring
- On device intelligence
- Customizable actions
- Device and system protection
- Cloud connection
- Configurable security levels
- Easy configuration and maintenance
Documents and Drivers
Documentation
CAN@net NT 100/200/420 User Manual
CAN-Gateway Configuator for CAN@net NT and CANbridge NT User Manual
CAN@net NT - Generic Protocol 2.1 for Gateway Mode V6 Software Design Guide
Lua ADK for CAN@net NT & CANbridge NT Software Design Guide
CAN@net NT C-API-ixcan
Downloads
VCI V4 - Windows 11, 10 [Driver, canAnalyser-Mini, Manuals, LabView and other add-ons]
Specifications
Content of Delivery
- CANbridge NT device
- User manual
- Mini USB cable
- DIN rail mount bracket
Available as free download:
- CAN-Gateway Configurator tool
- CAN driver VCI
- Simple CAN monitor "canAnalyser Mini"
Dimensions (W x H x D)
99 x 114.5 x 22.5 mm (3.9 x 5 x .9 in)
Weight
165 g ( .4 lb )
Mounting
DIN rail mount
Current Consumption
110 mA (24 V DC), 230 mA (12 V DC)
Input Voltage
9 V to 36 V DC, with overvoltage and polarity protection
Isolation
1 kV DC for 1 sec.
Termperature
Operating and Storage: -40°C ~ 85°C (-40°F ~ 185°F)
Relative Humidity
10 to 95%, non-condensing
Enclosure
IP20, Polyamide housing for top hat rail mounting
Certifications
- CE, UL, FCC, UKCA
- WEEE Category - IT and telecommunication equipment
Connectors / Input / Output
1 x RJ45 connector, 1 x Mini USB port, 3 x screw terminals (2 x fieldbus, 1 x power)
CAN Mode
- CAN high-speed (ISO 11898-2:2016)
CAN Baud Rate
5 kBit/s to 1 MBit/s
